Abdelfettah Hadij-ElHouati

Current optical communication systems rely on the use of wavelength division multiplexing (WDM) to keep up with the increasing data rate requirements. The wavelength demultiplexer is the key component to implement WDM systems. In this Letter, we design and experimentally demonstrate a demultiplexer based on a curved grating waveguide geometry that separates eight channels with a spacing of 10 nm (1249 GHz) around the central wavelength of 1550 nm. The fabricated device shows very low insertion loss ( ∼ 1 d B ) and a crosstalk (XT) below − 25 d B . This device leverages metamaterial index engineering to implement the lateral cladding on one side of the waveguide. This makes it possible to design a waveguide grating with highly directional lateral emission by operating in a regime where diffraction into the silica upper cladding is frustrated, thus suppressing losses due to off-chip radiation.

Diffraction gratings that redirect light propagating in a channel waveguide to an on-chip slab are emerging as important building blocks in integrated photonics. Such distributed Bragg deflectors enable precise shaping of slab confined beams for a variety of applications, including wavelength multiplexing, optical phased array feeding, and coupling interfaces for on-chip point-to-point communications. However, these deflectors suffer from significant losses caused by off-chip radiation. In this Letter, we show, for the first time, to the best of our knowledge, that off-chip radiation can be dramatically reduced by using the single-beam phase matching condition and subwavelength metamaterial refractive index engineering. We present a deflector design with losses below 0.3 dB, opening a path toward new applications of distributed Bragg deflectors in integrated photonics.

In integrated optical circuits light typically travels in waveguides which provide both vertical and horizontal confinement, enabling efficient routing between different parts of the chip. However, for a variety of applications, including on-chip wireless communications, steerable phased arrays or free-space inspired integrated optics, optical beams that can freely propagate in the horizontal plane of a 2D slab waveguide are advantageous. Here we present a distributed Bragg deflector that enables well controlled coupling from a waveguide mode to such a 2D on-chip beam. The device consists of a channel waveguide and a slab waveguide region separated by a subwavelength metamaterial spacer to prevent uncontrolled leakage of the guided mode. A blazed grating in the waveguide sidewall is used to gradually diffract light into the slab region. We develop a computationally efficient strategy for designing gratings that generate arbitrarily shaped beams. As a proof-of-concept we design, in the silicon-on-insulator platform, a compact ×75 Gaussian beam expander and a partial beam deflector. For the latter, we also demonstrate a prototype device with experimental results showing good agreement with our theoretical predictions. We also demonstrate via a rigorous simulation that two such couplers in a back-to-back configuration efficiently couple light, suggesting that these devices can be used as highly directive antennas in the chip plane.
